PTFE Teflon Flat Washers - DIN 125 A

2534 in stock now, more available within 14 days.
SKU: PFEWAM3
Regular price $0.21 AUD / each Ex. VAT
Regular price Sale $0.39 AUD Sale price $0.21 AUD Ex. VAT

Instant Quote Guarantee:
Submit a request for quote online by clicking the button below and it'll be delivered to your inbox within 5 mins.

Request For Quote

Need Help?
Our team are always happy to help!
Live Chat: Available from the bottom right of your screen.
Email: sales@highperformancepolymer.com
Phone: +44(0)1865 684080

Volume Discount Available

Volume discount is available on this product. Log in to our B2B portal using the link below to order online or request a quotation.

View Discounts

PTFE Teflon Flat Washers - DIN 125 A

Product Drawing

Flat Washer Dimension Table (ISO7089/DIN125A)
M Size Inside Diameter (mm) Outside Diameter (mm) Thickness (mm)
M1.6 1.7 3.7 0.25
M2 2.1 4.0 0.5
M2.6 2.7 6.0 0.5
M3 3.2 7.0 0.5
M4 4.3 9.0 0.8
M5 5.3 10.0 1.0
M6 6.4 12.5 1.6
M8 8.4 17.0 1.6
M10 10.5 21.0 2.0
M12 13.0 24.0 2.5
M16 17.0 30.0 3.0

Dimension Table

Dimensions for PTFE Teflon Flat Washers - DIN 125 A in all available sizes are shown according to the product drawing above.

Polytetrafluoroethylene (PTFE/Teflon) Datasheet

Follow the link below to view our PTFE data sheet. This includes properties such as mechanical, electrical, thermal and chemical resistance.

Download PDF

PTFE Key Properties

  • Exceptional Chemical Resistance - Perfect for applications in the pharma sector.

    Low Adhesive Properties - Ideal for application that require self lubrication.

    High UV Resistance - Low rates of deterioration in external applications.

    Low Water Absorption Rates - A great alternative to nylon.

  • - Max operation temperature 260°C

    - Ultra low weight

    - Flame resistance (V-0)

    - Abrasion resistance

    - Hydrolysis resistance

    - Great electrical insulating properties

  • - Non-Magnetic

    - Low thermal conductivity

    - Non-Corrosive

    - Material flexibility

    - Low coefficent of friction

    - High thermal stability

ISO 9001 Certified

Certified through Quality Veritas. High Performance Polymer conforms to the ISO9001 quality management system. Certificates available on request.

Certificate Of Conformity

Product certificate of conformity available on request, confirming the product manufacturing standard and material.

Material Certificates

Full material traceability and certification confirming the material data and raw material batch number, which can be traced back to the manufacturer.
